DOmini digital oscilloscope with PC management software – the compact solution for professionals.
DOmini digital oscilloscope with PC management software – the compact solution for professionals.
This oscilloscope is ideal for students, amateur radio (Arduino), experimental research, and electronic engineers.
Key Features:
- 6 measurement channels (4 analog + 2 digital)
- 4 measurement modes: Single, Normal (Standby), Auto, and Recorder
- Trigger capture from event occurrence
- Real-time Fourier analysis
- Waveform memory capacity: 13,200 measurements (up to 26,400 for logic analyzer)
- Sampling rate for analog channels: 5,000 to 1,000,000 measurements per second
- Sampling rate for digital channels: 5,000 to 12 million measurements per second
- Available voltage levels: +3.3V and +5V
- Probe calibration and unit configuration
- Compatible with standard oscilloscope probes (x1, x10)
- Voltage measurement range: ±5V, 0-10V (±15V, 0-30V) with x1 probe
- 10-bit ADC resolution
- 4 digital I/O PWM ports
- Digital interfaces: SPI, I2C, UART, 1-WIRE
Applications:
- Real-time analysis of analog and digital signals
- Frequency analysis using Fast Fourier Transform
- External device control via 4 I/O ports
- PWM signal generation from 3Hz to 10MHz
- IC testing with digital interfaces (SPI, I2C, UART, 1-WIRE)
- Voltage source (+3.3V and +5V) with up to 30mA output
- Data acquisition system for various sensors (temperature, humidity, irradiance, etc.)
- High-impedance state detection for input/output ports (Z-state)
